Description
Output and consumption
- Energy efficiency class: E
- Energy consumption per year: 171 kWh/a
- Climate class: SN-T
- Noise level: 34 dB
- Refrigerant R: 600a
- Voltage: 220-240 V ~
- Frequency: 50-60 Hz
- Connection rating: 1.2 A
Control and functions
- Control: Monochrome LC display, touch display
- Control unit: Touch
- Number of temperature zones: 2
- Number of regulated refrigeration circuits: 1
- Temperature display: Refrigerator
- SuperCool: Adjustable on appliance and via app
- Door alarm, cooling: Adjustable on appliance and via app
- Door alarm, freezing: —
- BottleTimer: —
- Connectivity solution: retrofittable
- NightMode: Adjustable on app
- Display lock: Adjustable on appliance
Refrigerator compartment
- Adjustable temperature range, refrigerator compartment: +2 °C to +9 °C
- Refrigerator compartment climate zones: EasyFresh with universal drawer
- Defrosting method: automatic
- Forced air cooling: ✔
- FreshAir filter: in valve
- Pull-out system drawer, refrigerator compartment: Partially-extendible telescopic rails
- Illumination cooling compartment: Light, both sides
- Number of storage shelves, refrigerator compartment: 5
of which separable: 0
of which height-adjustable: 2 - VarioSafe: —
- OpenStage drawers: —
- Bottle storage: Bottle rack
- Bottle rack: 2
- Number of can racks: 0
- VarioBox: —
- VarioBoxes: 0
- Butter dish: —
- Egg tray: 10 eggs
- Type of door rack: Cooling compartment Bottle and can rack
- Height-adjustable inner door shelf: Gradual adjustment
Freezer compartment
- Storage time in case of fault according to GS *: 14 h
- Freezing capacity in 24 hours according to GS *: 2.00 kg / 24h
- 4-star freezer compartment door: Hinged, towards front
- Number of glass shelves, 4-star freezer compartment: 1
- Star-rating: 4
Design and materials
- Dry rear panel: —
- Inner back wall material: —
- Inner door décor: —
- Material inner door rack: White plastic
- Storage shelf material, refrigerator compartment: Glass
Set-up and installation
- Type of installation: Designed for integrated use
- Door assembly: Fixed door
- Max. kitchen unit door weight: 26
- Door hinges: Right reversible
- Door hinge replacement: Possible for customer
- Door opening angle: 115°
- Door seal: Replaceable
- Height-adjustable feet: 2
- Levelling bars: ✔
- Number of levelling bars: 2
- Ventilation: Ventilation grates
- Connector cable (length): 2,200 mm
Specifications
- Aperture dimensions height/width/depth: 177.2 – 178.8 / 56 – 57 / 55 cm
- Height / Width / Depth (with packaging): 1,829 / 572 / 622 mm
- Dimensions H/W/D: 177 / 55.9 / 54.6 cm
- Weight (without packaging): 57.2 kg
- Weight (with packaging): 60.7 kg
- Total volume **: 286 l
- Volume, refrigerator compartments: 259 l
- Volume, freezer compartments: 27 l
of which 4-star compartment: 27.1 l
.
.
.
